| Numer części | LH550WF4-SD01 |
| Marka | LG Display |
| Rozmiar | 5.5 |
| Aplikacja | MPH |
| Rezolucja | 1080×1920 |
| Kompozycja | Assembly |
| Jasność | 550 |
| CR | 1600:1 |
| Zabarwienie | 16.7M |
| Podświetlenie | WLED |
| Interfejs | MIPI |
| marka panelu | LG Display |
| model panelowy | LH550WF4-SD01 |
| typ panelu | LTPS TFT-LCD , Assembly |
| rozmiar panelu | 5.5 inch |
| rezolucja | 1080(RGB)×1920 , FHD |
| aktywny obszar | 68.364×121.536 mm |
| zarys | 75.27×155.55×2.35 mm |
| powierzchnia | |
| jasność | 550 cd/m² (Typ.) |
| Współczynnik kontrastu | 1600:1 (Typ.) |
| wyświetlać kolory | 16.7M (8-bit), CIE193170% |
| Kąt widzenia | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| częstotliwość | 60Hz |
| interfejs sygnału | MIPI (4 data lanes), 36 pins |
| Napięcie wejściowe | 1.8//5.7/-5.7V (Typ.)(DVDD/AVDDH/AVDDN) |
| aplikacja | MPH |
